A stand that works effortlessly for lubricating a chain can completely block your hands when trying to slide out a rear axle or drop the front forks. Selecting motorcycle support hardware starts with the geometry of your swingarm, the diameter of your steering stem bore, and the rigidity of the stand's main hoop.
Multi-piece flat-pack stands often flex at the bolted joints when supporting bikes over 190 kg, causing theY-hooks to twist outward under load. Choose one-piece TIG-welded 38 mm steel or thick-wall aluminum hoops with dual polyurethane wheels per side.
Yamaha and Aprilia commonly use M6×1.0; Suzuki, Honda, BMW, and Triumph frequently use M8×1.25; Kawasaki uses either M8×1.25 or fine-pitch M10×1.25; KTM uses standard M10×1.5. Never force a coarse M10×1.5 bolt into a fine-pitch Kawasaki boss.
Place the transmission in neutral or first gear depending on whether you need to spin the rear wheel. Tuck a 25 mm wood block under the sidestand foot so the motorcycle sits nearly vertical. Align both rear stand V-hooks beneath the swingarm spools, steady the tail section with your left hand, and press the stand handle all the way to the floor in one smooth stroke.
Only after the rear wheel is supported on a wide-base rear stand should you position the front stand. Center the handlebars, verify that radial brake lines and ABS sensor wires are clear of the cradle pins, and lever the front wheel upward.
Before lowering either stand, verify that the sidestand is fully deployed down and forward. Lower the front wheel to the ground first and remove the front stand completely. Then stand on the left side of the bike, hold the left handlebar or grab rail, ease the rear stand up, and gently lean the bike onto its sidestand.
